- High quality imaging with 8 MP resolution
- Efficient H.265+ compression technology
- Clear imaging against strong backlight due to 130 dB WDR technology
- Built-in microphone for real-time audio security(-U)
- Focus on human and vehicle targets classification based on deep learning
- 24/7 colorful imaging
- Water and dust resistant (IP67)
Camera | |
Image Sensor | 1/1.2″ Progressive Scan CMOS |
Max. Resolution | 3840×2160 |
Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON) |
Shutter Speed | 1/3 s to 1/100,000 s |
Day & Night | 24/7 Color imaging |
Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
Lens | |
Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
Focal Length & FOV | 2.8 mm, horizontal FOV 102°, vertical FOV 52°, diagonal FOV 124° |
Lens Mount | M16 |
Iris Type | Fixed |
Aperture | F1.0 |
Depth of Field | 2.8 mm: 3.1 m to ~ |
DORI | |
DORI | 2.8 mm: D: 96 m, O: 38 m, R: 19 m, I: 9 m |
Illuminator | |
Supplement Light Type | White Light |
Supplement Light Range | Up to 30 m |
Smart Supplement Light | Yes |
Video | |
Main Stream | 50 Hz: 25 fps (3840 x 2160, 3200 x 1800,2688 x 1520, 1920 x 1080, 1280 x 720)
60 Hz: 24 fps (3840 x 2160) 30 fps (3200 x 1800,2688 x 1520, 1920 x 1080, 1280 x 720) |
Sub-Stream | 50 Hz: 25 fps (640 x 480, 640 x 360)
60 Hz: 30 fps (640 x 480, 640 x 360) |
Third Stream | 50 Hz: 10 fps (1920 x 1080, 1280 x 720, 640 x 480, 640 x 360)
60 Hz: 10 fps (1920 x 1080, 1280 x 720, 640 x 480, 640 x 360) |
Video Compression | Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
Video Bit Rate | 32 Kbps to 16 Mbps |
H.264 Type | Baseline Profile/Main Profile/High Profile |
H.265 Type | Main Profile |
Bit Rate Control | CBR/VBR |
Scalable Video Coding (SVC) | H.264 and H.265 encoding |
Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
Audio | |
Environment Noise Filtering | -U: Yes |
General | |
Power | -L:
12 VDC, 0.42 A, max. 5 W PoE: 802.3af, 36 V to 57 V, 0.17 A to 0.11 A, max. 6.0 W -LU: 12 VDC, 0.46 A, max. 5.5 W PoE: 802.3af, 36 V to 57 V, 0.18 A to 0.11 A, max. 6.5 W |
Material | Cover: metal, main body: metal |
Dimension | 0138.3 mm x 120.1 mm (05.4″ x 4.7″) |
Package Dimension | 170 mm x 170 mm x 150 mm (6.7″ x 6.7″ x 5.9″) |
Weight | Approx. 870 g (1.9 lb.) |
With Package Weight | Approx. 1160 g (2.6 lb.) |
Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Language | 33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
General Function | Anti-flicker, heartbeat, mirror, password reset via e-mail, pixel counter |
Software Reset | Yes |
Approval | |
EMC | FCC (47 CFR Part 15, Subpart B)
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014) RCM (AS/NZS CISPR 32: 2015) IC (ICES-003: Issue 7) KC (KN32: 2015, KN35: 2015) |
Safety | UL (UL 62368-1)
CB (IEC 62368-1: 2014+A11) CE-LVD (EN 62368-1: 2014/A11: 2017) |
Environment | CE-RoHS (2011/65/EU)
WEEE (2012/19/EU) Reach (Regulation (EC) No 1907/2006) |
Protection | IP67 (IEC 60529-2013) |
