SPRO 2MP/5MP Lite 8CH 5-in-1 HD CCTV DVR Recorder with AI DHDVR12-B5-V5
£141.12 Original price was: £141.12.£119.99Current price is: £119.99. inc VAT
Out of stock
Description
KEY FEATURES:
- 12 channel recording (8 channel BNC + 4 channel 5MP IP)
- 5 IN 1 (CVI/TVI/AHD/ANALOGUE/IP)
- H.265 video compression
- 5M-N recording@10fps, 1080P@15fps
- Supports 2-Way Audio
- Supports up to 5MP on extra IP channels
- Supports Analogue Audio over Coax (SPRO compatible cameras required)
- Supports “IP Audio over CAT5E” on extra IP channels (compatible cameras required)
- P2P mobile phone setup (no port forwarding or complicated setup)
- Clip live video or recordings while viewing playback on your phone
- SMD PLUS (smart motion detection plus) & Perimeter protection
- Intrusion & tripwire (human & vehicle classification)
- Face detection 2.0
SPECIFICATIONS:
| Model Number | DHDVR12-B5-V5 |
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Video & Audio | |
| Input | 12 channel (8 x BNC + 4 x IP) |
| Standard – BNC | 8 channel CVI/TVI/AHD/ANALOGUE |
| Standard – IP | 4 channel (up to 5MP-N IP) |
| Analog Camera Input | 8 Channel, BNC |
| HDCVI Camera | 5MP-N@10fps, 4MP-N@15fps, 1080P@25fps, 720P@25/50fps |
| AHD Camera | 5MP-N@10fps, 4MP-N@15fps, 1080P@25fps, 720P@25fps |
| TVI Camera | 5MP-N@10fps, 4MP-N@15fps, 1080P@25fps, 720P@25fps |
| CVBS Camera | PAL/ NTSC |
| IP Camera Input | 4 Channel, each channel up to 5MP-N@10fps, 2MP@25fps |
| Audio In/Out | 1/1 RCA, Audio over co-ax supported on all BNC Channels |
| Two-way Talk | Reuse audio in/out, RCA |
| Recording | |
| Video/Audio Compression | H.265+/ H.265/ H.264+/ H.264 |
| Resolution | 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF |
| Record Rate – Main Stream | 5M-N (1-10fps), 4M-N/1080P (1~15fps)/ 1080N/ 720P/ 960H/ D1/ CIF (1~25fps) |
| Record Rate – Extra Stream | D1/ CIF/ QCIF (1~15fps) |
| Bit Rate | 32Kbps–6144Kbps Per Channel |
| Record Mode | Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval | 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Audio Compression | AAC (only for the 1st channel), G.711A, G.711U, PCM |
| Audio Sample Rate | 8KHz, 16 bit Per Channel |
| Audio Bit Rate | 64Kbps Per Channel |
| Display | |
| Interface | 1 HDMI, 1 VGA |
| Resolution | HDMI: 1296X1944, 1920×1080, 1080X960, 1280×720 VGA: 1296X1944, 1920×1080, 1080X960, 1280×720 |
| Multi-screen Display | When IP extension mode not enabled: 1/4/8/9 When IP extension mode enabled: 1/4/8/9/16 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Network | |
| Interface | 1 RJ-45 port (100M) |
| Network Functions | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android Phone |
| Interoperability | ONVIF 16.12, CGI Conformant |
| Video Detection and Alarm | |
| Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Playback & Backup | |
| Sync Playback | 1/4/9 |
| Search Mode | Time/Date, MD & Exact search (accurate to second) |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode | USB Device/ Network |
| Storage | |
| Internal HDD | 1 SATA port, up to 10TB |
| Auxiliary Interface | |
| USB Interface | 2 ports(1 Rear), USB2.0 |
| RS485 | 1 port, For PTZ Control |
| General | |
| Power Supply | DC12V/2A |
| Power Consumption | <10W (without HDD) |
| Working Environment | -10°C ~+55°C / 10%~90%RH |
| Storage Conditions | -20°C ~+70°C / 10%~90%RH |
| Dimensions | Compact 1U, 260mm × 220mm × 40mm |
| Weight | 1.2KG (without HDD) |
| Perimeter Protection | |
| Perimeter Protection | 1. AI by DVR: Detection alarm for human and vehicle. Filter misinformation such as leaves and light. 2. Function configuration: Set at most 10 rules such as area intrusion and tripwire intrusion. 3. Performance: 2 channels |
| Live View | 1. Rule box inspection: Configure the rule box and object inspection box. 2. Smart panel: Display object classification (human, vehicle), event types, triggering time, image matting and object types. Attribute is not supported. 3. Counting: Count people in Peopletotal. Count motor vehicles in Vehicle. Support exporting of associated event playback before and after 10 seconds. |
| Playback | 1. Search conditions: According to channels, time, event types and target types. 2. Functions: Support search of associated event playback or snapshot before and after 10 seconds. 3. Snapshot capacity: 500,000 |
| Face Recognition | |
| Performance | 1. UP to 12 face pictures/sec processing (modeling and comparing). 2. Up to 2 channels video stream (analog channel ) human face recognition. 3. Up to 10 face databases with 10,000 face images in total. 4. Up to 300,000 face detection events in total. 5. Up to 300,000 face Recognition events in total. |
| Stranger Mode | Detect strangers’ faces (not in device’s face database). Similarity threshold can be set manually. |
| AI Search | Up to 8 target face images search at same time, similarity threshold can be set for each target face image. |
| Database Management | Up to 10 face databases with 10,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture. |
| Database Application | Each database can be applied to video channels independently. |
| Trigger Events | Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc. |
| SMD Plus | |
| SMD Plus | 1. AI by DVR: Motion detection alarm for human and vehicle. Filter misinformation such as leaves and light. 2. Performance: 8 channels , AI by DVR |
| Preview | Preview: Configure and inspect detection box |
| Playback | 1. Playback: Search videos through channels, time and target types. 2. Functions: Support search of associated event playback before and after 10 seconds. |
Additional information
| Brand | SPRO |
|---|---|
| Channels | 8 Channel |
| Resolution | 2 MegaPixel, 5 MegaPixel |
| Technology | 5-in-1 |
