Dahua IP Villa Door Station KTP04

System

Main Processor

Embedded processor

Operating System

Embedded Linux Operation System

Button Type

Mechanical

Interoperability

ONVIF; CGI

Network Protocol

SIP; P2P; IPv4; UPnP; SNMP; DNS; DDNS; RTSP; RTP; TCP; UDP

Basic

Camera

1/2.9″ 2MP CMOS Low Illumination HD Colorful Camera

Field of View

Horizontal: 138.6°; vertical: 79.6; diagonal:159°

Focal Length

2.0 mm

WDR

120 dB

Noise Reduction

3D NR

Video Compression

H.265

Video Resolution

50 Hz:
Main Stream (720p@25 fps), sub stream (1080p@25 fps)
60 Hz:
Main Stream (720p@30 fps), sub stream (1080p@30 fps)

Video Frame Rate

25 fps

Video Bit Rate

256 Kbps to 8 Mbps

Light Compensation

Auto IR

Day/Night

Auto (ICR)

Audio Compression

G.711a; G.711u; PCM

Audio Input

1 channel

Audio Output

Built-in speaker

Audio Mode

2-way voice communication

Audio Enhancement

Echo suppression/digital noise reduction

Audio Bit Rate

16 kHz, 16 Bit

Status Indicator Light

3

Port

RS-485 Port

1

Alarm Output

1

Power Output

1-ch 12 VDC 100 mA

Exit Button

1

Door Status Detection

1

Lock Control

1

Network Port

One RJ45 10M/100M network port

General

Appearance color

Silver

Power Supply

24 VDC, 1 A
Standard PoE

Power Adapter

Optional

Installation

Flush mount

Certifications

CE; FCC; UL

Product Dimensions

130 mm × 96 mm × 28.5 mm (5.12″ × 3.78″ × 1.12″)

Protection

IK07; IP65

Operating Temperature

–30°C to +60°C (–22°F to 140°F)

Operating Humidity

10%–90% (RH, non-condensing)

Operating Altitude

0 m–3000 m

Power Consumption

≤ 8W

Net Weight

0.35 kg (0.77 lb)

Gross Weight

0.4 kg (0.88 lb)

DHI-VTH5421HW

System

Main Processor

Embedded processor

Operating System

Embedded Linux Operation System

Button Type

Touch keypad

Interoperability

ONVIF

Network Protocol

SIP; IPv4; RTSP; RTP; TCP; UDP

ROM

128 MB

RAM

128 MB

CPU

Dual-core 1.2 GHz

Basic

Screen Type

Capacitive

Display Screen

7-inch TFT

Resolution

1024 × 600

Audio Compression

G.711a; G.711u; PCM

Audio Input

1

Audio Output

Built-in speaker

Audio Mode

2-way voice communication

Audio Enhancement

Echo suppression

Audio Bit Rate

16 kHz, 16 Bit

Communication Mode

Full digital

Information Release

Supports viewing text announcement from the center ( insert an SD card to receive and view pictures)

Leave Videos

Yes (SD card inserted in VTH is needed)

Storage

Micro SD, Max 64 GB

Port

RS-485

1

Alarm Input

6

Alarm Output

1

Power Output

1.12 V/100 mA

Door Bell

Yes, reusing any alarm input port

Network Port

One 10 Mbps/100 Mbps Ethernet port

General

Casing

PC + ABS

Appearance color

White

Power Supply

12 VDC, 1A

Standard Poe

Power Adapter

Optional

Installation

Surface mount

Certifications

CE; FCC; UL

Accessory

Bracket (standard)
Alarm ribbon cable (standard)

Product Dimensions

189.0 mm × 130.0 mm × 26.9 mm (7.44″ × 5.12″ × 1.06″)

Operating Temperature

–10°C to +55°C (14°F to 131°F)

Operating Humidity

10%–95% (RH, non-condensing)

Operating Altitude

0 m–3,000 m

Power Consumption

Standby ≤ 2 W, working ≤ 6 W

Net Weight

0.388 kg (0.86 lb)

Gross Weight

0.74 kg (1.63 lb)

PFS3006-4ET-36

General

Network Port

4 PoE ports with 10/100 Mbps Base-TX

2 uplink ports with 10/100Mbps Base-TX

Appearance color

black

Power Supply

100–240 VAC

PoE Budget

Port1-4 ≤30 W, whole PoE budget ≤36 W

Certifications

CE; FCC; UL

Product Dimensions

194.0 mm × 108.1 mm × 35.0 mm (7.64″ × 4.26″ × 1.38″)

Operating Temperature

–10°C to +55°C (14°F to 131°F)

Operating Humidity

5%°–95% (RH, non-condensing)

Operating Altitude

0 m–3000 m

Net Weight

0.56 kg (1.23 lb)
