Dahua 16 Camera 5MP Smart Dual Light PoC CCTV Kit with Audio Recording

Sixteen PoC cameras on one recorder, each on its own coax cable and nothing else. No power box, no splitter leads.

The DH-XVR5216AN-4KL-I3-16P powers every channel over the coax and records all sixteen at 5MP. It has two hard drive bays, so you can keep weeks of footage on a busy site. WizSense picks out people and vehicles, which keeps the DMSS alerts worth opening. Pick the hard drive size in the recorder’s own options.

Any RG59 or RG6 coax works for PoC. Our 20m plug-and-play cable is in the list if you want runs made up; its power pair simply stays unused.

About the camera: DH-HAC-HDW1509TP-IL-A-POC

A 5MP (2880 × 1620) HDCVI eyeball that takes its power down the same coax as the video. On a PoC recorder that is one cable per camera and nothing else to run.

Smart Dual Light is worked by the recorder. The camera sits on infrared at night. When the XVR's perimeter protection or SMD Plus spots a person or vehicle in a zone you set, the camera turns its warm light on for a colour picture, then drops back to infrared once they have gone. Light reaches up to 40 m. There is a microphone built in, and the 120 dB WDR copes with headlights and bright windows.

What is in the kit

Need fewer cameras? The 4 or 8 camera version of this kit uses the same camera.

On a tighter budget? The Lite version of this kit records in 5MP Lite on a lower-cost recorder.
